Phosphor Bronze Washer Manufacturer, Phosphorus Bronze Spring Washers Suppliers, Pb Washer Din 7980 Supplier, Phosphorus Bronze Spring Washer, Grade Din 7980 Washer, Phosphor Bronze Flat Washer Manufacturer In India
Pearl Shims is the leading Phosphorus Bronze Spring Washer Manufacturers in India. These Phosphor Bronze Din Washers are made of high-quality phosphor bronze (a copper, tin, and phosphorus alloy) material, which gives them a high wear resistance, low friction, and high elasticity over traditional spring washers. We manufactures these Phosphor Bronze Washers in various types, such as Phosphorous Bronze punched washer, Phosphorous Bronze lock washer, Phosphorous Bronze Flat washer, Phosphorous Bronze Spring Washers, and Phosphorous Bronze Dock Washer.
Table Of Content
- About Pb Washer Din 7980 Manufacturers
- Phosphorus Bronze Washers Specifications
- Phosphorus Bronze Washers Size Chart
- Frictional Coefficient OF Pb Washer Din 7980
- Weight Chart of PB Flat Washer Din 7980
- Phosphorous Bronze C52100 Spring Washer Dimensions
- Stocks Available For Phosphorus Bronze Spring Washers
- Applications of Phosphorus Bronze Washers
- Marking & Packing of SS Phosphorus Bronze Washers
- Cities We Deliver PB Washer Din 7980
- Countries We Export Phosphorus Bronze Spring Washer
ASTM C54400 Phosphorous Bronze Punched Washer, Phosphorus Bronze Spring Flat Washer Exporter, PB Spring lock washer Manufacturer, Pb Spring Washer Supplier, Phosphorous Bronze Hexagonal Washer Dealer, Pb Spring Spherical Washer Manufacturer in India
Pearl Shims is an established manufacturer of Phosphorus Bronze Spring Washers in India that provides quality components to be used in critical industries. Phosphorus Bronze Spring Washers are designed to resist loosening when subjected to vibration, offer a long service life, and provide the tension required in bolts, making them perfectly suitable for industries that require reliability, accuracy, and predictability.
We also have a selection of PB C54400 Fender Washers in M3 to M30 sizes and up to 100mm long that can be used in different mechanical assemblies. We also have ASTM C54400 Phosphorous Bronze Flat Washer, which comes with excellent conductivity, corrosion, and mechanical strength in unfavorable conditions. We are also Stainless Steel Shim Manufacturer in India
Phosphorus Bronze Spring Washers Supplier - Specifications
| CuSn8p Washer Sizes | M2-M24 |
| PB Washer Size Metric |
|
| Phosphor Bronze Washer Size Inch |
|
| Material Origin | Phosphor Bronze Washers are Western European. Eastern origin possible on request. |
| Phos Bronze Washer types | belleville, flat, bowed, cup, pivot, disc, spring, and tension. |
| MOQ | 5 pieces |
| Free Samples | Yes |
| Delivery time | Regular product is about 7-15 days |
| Payment Terms | T/T, Western Union, Paypal, L/C or Trade Assurance 30% deposit & balance before shipping |
| Port of Dispatch | Mumbai or Kalamboli ports in Maharashtra state of India |
| Features of PB washers |
|
Other Washer We Supply
Phosphorus Bronze Washer Din 7980 Size Chart
| Size | USS | SAE | ||||
| OD (in.) | ID (in.) | tdickness | OD (in.) | ID (in.) | tdickness | |
| 1/8 (#6) | - | - | - | 0.375 | 0.156 | .036/.065 |
| 5/32 (#8) | - | - | - | 0.438 | 0.188 | .036/.065 |
| 3/16 (#10) | 0.560 | 0.250 | .036/.065 | 0.500 | 0.220 | .036/.065 |
| 7/32 (#12) | - | - | - | 0.562 | 0.250 | .051/.080 |
| 1/4 (#14) | 0.734 | 0.312 | .051/.080 | 0.625 | 0.281 | .051/.080 |
| 5/16 | 0.875 | 0.375 | .064/.104 | 0.688 | 0.344 | .051/.080 |
| 3/8 | 1.000 | 0.438 | .064/.104 | 0.812 | 0.406 | .051/.080 |
| 7/16 | 1.250 | 0.500 | .064/.104 | 0.922 | 0.469 | .051/.080 |
| 1/2 | 1.375 | 0.562 | .086/.132 | 1.062 | 0.531 | .074/.121 |
| 9/16 | 1.469 | 0.625 | .086/.132 | 1.156 | 0.594 | .074/.121 |
| 5/8 | 1.750 | 0.688 | .108/.160 | 1.312 | 0.656 | .074/.121 |
| 3/4 | 2.000 | 0.812 | .122/.177 | 1.469 | 0.812 | .108/.160 |
| 7/8 | 2.250 | 0.938 | .136/.192 | 1.750 | 0.938 | .108/.160 |
| 1 | 2.500 | 1.062 | .136/.192 | 2.000 | 1.062 | .108/.160 |
| 1 1/8 | 2.750 | 1.250 | .136/.192 | 2.250 | 1.250 | .108/.160 |
| 1 1/4 | 3.000 | 1.375 | .136/.192 | 2.500 | 1.375 | .136/.192 |
| 1 3/8 | 3.250 | 1.500 | .153/.213 | 2.750 | 1.500 | .136/.213 |
| 1 1/2 | 3.500 | 1.625 | .153/.213 | 3.000 | 1.625 | .153/.213 |
| 1 5/8 | 3.750 | 1.750 | .153/.213 | - | - | - |
| 1 3/4 | 4.000 | 1.875 | .153/.213 | - | - | - |
| 1 7/8 | 4.250 | 2.000 | .153/.213 | - | - | - |
| 2 | 4.500 | 2.125 | .153/.213 | - | - | - |
| 2 1/4 | 4.750 | 2.375 | .193/.248 | - | - | - |
| 2 1/2 | 5.000 | 2.625 | .210/.280 | - | - | - |
| 2 3/4 | 5.250 | 2.875 | .228/.310 | - | - | - |
| 3 | 5.500 | 3.125 | .249/.327 | - | - | - |
Frictional Coefficient OF PB Spring ASTM C54400 Washer
| Material | Surface Finish | Frictional Coefficient | ||
| Static - μstatic - |
Kinetic (sliding) - μsliding - |
|||
| Phosphor-bronze | Steel | Clean and Dry | 0.35 | |
| Bronze | Steel | Lubricated and Greasy | 0.16 | |
| Bronze | Steel | Lubricated and Greasy | 0.16 | |
| Bronze | Cast Iron | Clean and Dry | 0.22 | |
| Bronze - sintered | Steel | Lubricated and Greasy | 0.13 | |
Weight Chart of PB Flat Washer Din 7980
| tdread Size | Weight chart per 100 (kg) | Pack Quantity |
| M6 | 0.05 | 100 |
| M8 | 0.15 | 100 |
| M10 | 0.25 | 100 |
| M12 | 0.50 | 100 |
Phosphorous Bronze C52100 Spring Washer Dimensions
| NOM SIZE | Inner Dia (d) Basic Tol (+) | Outer Dia (d1) Max | WIDTH (b) Basic Tol (+ or -) | THICKNESS (S) Basic Tol (+ or -) | Weight per 1000 in Kgs | |||
| 3 | 3.1 | 0.3 | 6.2 | 1.3 | 0.1 | 0.8 | 0.1 | 0.11 |
| 4 | 4.1 | 0.3 | 7.6 | 1.5 | 0.1 | 0.9 | 0.1 | 0.18 |
| 5 | 5.1 | 0.3 | 9.2 | 1.8 | 0.1 | 1.2 | 0.1 | 0.36 |
| 6 | 6.1 | 0.4 | 11.8 | 2.5 | 0.15 | 1.6 | 0.1 | 0.83 |
| 8 | 8.1 | 0.4 | 14.8 | 3 | 0.15 | 2 | 0.1 | 1.60 |
| 10 | 10.2 | 0.5 | 18.1 | 3.5 | 0.2 | 2.2 | 0.15 | 2.53 |
| 12 | 12.2 | 0.5 | 21.1 | 4 | 0.2 | 2.5 | 0.15 | 3.82 |
| 14 | 14.2 | 0.5 | 24.1 | 4.5 | 0.2 | 3 | 0.15 | 6.01 |
| 16 | 16.2 | 0.8 | 27.4 | 5 | 0.2 | 3.5 | 0.2 | 8.91 |
| 18 | 18.2 | 0.8 | 29.4 | 5 | 0.2 | 3.5 | 0.2 | 9.73 |
| 20 | 20.2 | 1 | 33.6 | 6 | 0.2 | 4 | 0.2 | 15.20 |
| 22 | 22.5 | 1 | 35.9 | 6 | 0.2 | 4 | 0.2 | 16.50 |
| 24 | 24.5 | 1 | 40 | 7 | 0.25 | 5 | 0.2 | 26.20 |
| 27 | 27.5 | 1 | 43 | 7 | 0.25 | 5 | 0.2 | 28.70 |
| 30 | 30.5 | 1.2 | 48.2 | 8 | 0.25 | 6 | 0.2 | 44.30 |
| 33 | 33.5 | 1.2 | 55.2 | 10 | 0.25 | 6 | 0.2 | 63.00 |
| 36 | 36.5 | 1.2 | 58.2 | 10 | 0.25 | 6 | 0.2 | 67.30 |
| 39 | 39.5 | 1.2 | 61.2 | 10 | 0.25 | 6 | 0.2 | 71.70 |
| 42 | 42.5 | 1.2 | 68.2 | 12 | 0.25 | 7 | 0.25 | 111.00 |
| 45 | 45.5 | 1.2 | 71.2 | 12 | 0.25 | 7 | 0.25 | 117.00 |
| 48 | 49 | 1.5 | 75 | 12 | 0.25 | 7 | 0.25 | 123.00 |
| 52 | 53 | 1.5 | 83 | 14 | 0.25 | 8 | 0.25 | 320.00 |
